Xpress Hyper-Lift Bay Series boats are the SOLUTION. Built on the foundation of our Hyper-Lift Hull, this dream craft packs performance, fishability, and comfort into one amazing cost-effective boat. In thin water or rough seas, you will not find a better solution. Whether this is your first bay boat or you intend to make this the last bay boat you buy, the Xpress Hyper-Lift Bay Series will satisfy!
 | H24B w/Yamaha VF175LB $44,995 |
 | H22B w/Yamaha VF175LB $42,295* *Includes Uflex Upgrade |
 | H20B w/Yamaha VF115LB $34,695 |
Scroll or Rotate to see specs
| H24B | H22B | H20B | |
|---|---|---|---|
| Length | 24′ | 22′ | 20’3″ |
| Bottom | 67″ | 67″ | 67″ |
| Beam | 95” | 95” | 95” |
| Sides | 24″ | 24″ | 24″ |
| Transom Height | 22” | 22” | 22” |
| Fuel Tank Capacity | 40 gal. | 40 gal. | 40 gal. |
| Approx Weight | 1,659 lb. | 1,528 lb. | 1,436 lb. |
| Max Wt./Per/Mo/GR | 2,169 lb. | 2,000 lb. | 1,900 lb. |
| Total Wt. Per Cap | 10 / 1,410 lb. | 8 / 1,128 lb. | 8 / 1,128 lb. |
| Aluminum – 5052 Gauge | 0.125 | 0.125 | 0.125 |
| Maximum HP | 250 | 115-150-200* | 115-150* |
| Overall Package Length | 30’6″ | 27’10” | 25′ |
| BackTrack Trailer Model | AW24 | AW22 | AW20 |
Click the + below to expand and view additional information.
Standard Features
Hyper-Lift Hull
All-Welded Construction
Longitudinal Rib Construction
Unibody Injected Foam Construction
Gulfsand Paint w/Xtreme Coat Liner
SeaDek Console Top
Xclusive Graphics
SeaDek Step Pad on Bow
Dash Panels w/Multifunction Gauge (Includes Hour Meter)
Logo Badge
Xtreme Liner in Front Deck & Rod Boxes
NEW Stainless Boarding Ladder
Tackle Storage Behind Console Backrest
SeaDek Pads in Rod Boxes
Coolers Under Jump Seats
Drop In Liner for Front Deck Storage
Walkboards w/Cupholder
Center Console w/Toekick Feature
NEW Stainless Steel Steering Wheel w/Logo
2 Fold Down Fishing Seats w/13” Extensions
2 Built-in Lockable Rod Boxes
8 Gauge Trolling Motor Harness
Alum Leaning Post w/Cushion and Foot Rest
Large Bay Center Console with Baitwell, Fold Down Grabrail, Removable Windshield, Seat Cushion & Back-Rest Cushion
Aerated Livewell in Rear Deck
Thru Transom Hydraulic Hose Fittings (H22B & H24B)
8 Rod Holders on Console
4 Cup Holders on Console
2 Rear Deck Jump Seats with Storage Underneath
Latches for Jump Seat Lids
Stainless Floor Drain Covers
Humminbird PiranhaMax 4 Graph
Minn Kota Riptide 46 Trolling Motor
Running Lights
Uflex Hydraulic Steering Greater than 150HP (H24B Only)
BackTrack Single Axle Aluminum Trailer
BackTrack Tandem Axle w/ Brakes Aluminum Trailer (H24B Only)
Options
Charger
2 Bank
3 Bank
2 Bank to 3 Bank Upg.
Console
AM/FM Radio w/ Bluetooth & Speakers
Wet Sounds Premium Sound System – 4 Speakers
Wet Sounds Premium Sound w/RGB Under Rail Lights
Construction
Reinforced Floor for T-Top
Controls
Pre-Rig Binnacle Mount Control Box w/Cables
Graphs
Garmin
Humminbird
Hardware
High Pressure Wash Down Station
Storage Box Against Front Deck Baffle
Jack Plate
6” Jack Plate
6” Atlas Hydraulic Jack Plate
10” Jack Plate
10” Atlas Hydraulic Jack Plate
Ladder
Permanent Ladder
Paint
2 Tone Upgrade From Standard
2-Tone Camo Paint Upg w/ Brown Interior
Xtreme Coat Console (Any Color)
Painted Console (Except GS & White)
Prop
Upgrade to PowerTech SS SM/Med Hub Prop
Upgrade to PowerTech SS Large Hub Prop
Upgrade to Yamaha SS Large Hub Prop
SeaDek
SeaDek Liner for H20B/H22B/H24B
SeaDek Helm Pad
Seat
Front Jump Seat w/Storage Box Against Front Deck
Bay Boat Rod Box Cushion Set
Upgrade To SS Leaning Post w/Backrest & Footrest from SS Leaning Post
Exchange Fold Down Seat for Euro Style Seat (Each)
Exchange Folddown for Aero-X Mesh Seat
Exchange Euro for Aero-X Mesh Seat
Shallow Water Anchors
MinnKota Raptor
Power-Pole Blade
Steering
BayStar Plus Hydraulic (150HP or Less)
BayStar Plus Hydraulic (150LD or F200LD)
SeaStar Hydraulic Tilt (Greater Than 150HP)
Seastar Hydraulic Tilt (150LD or F200LD)
Uflex Hydraulic (Greater Than 150HP)
Uflex Hydraulic (150LD or F200LD)
Upgrade Uflex to SeaStar
Trolling Motors
Garmin
Minn Kota
Power-Pole Move
Wiring
6 Gauge TM Harness (Reg. Upg. For All 80lb & Larger TM’s)
Lights in Livewells, Storage Boxes & Interior
BackTrack Trailer Options
Lighted Logo Trailer Step (Both Sides)
Aluminum Spare Tire and Mount
15” Aluminum Spare Tire & Mount
Aluminum Wheel Upgrade (Per Axle)
Brakes on Second Axle of Tandem
Single Axle w/Brakes
Galvanized Spare Tire and Mount
Swing Away Tongue
Tandem Axle w/Brakes on One Axle
Tandem Axle w/Brakes on Both Axles
15” Aluminum Wheel Upgrade From 14” Alum
18” Aluminum Spare Tire & Mount
Packages
Saltwater Trailer Package
Composite Bunk Covers and Upgraded Bow Roller.
Xtreme Trailer Package (Req. Tandem/Brake w/ Alum Wheels)
18” Aluminum Wheel Upg (2 Axles), Custom Tread Plate Tandem Fenders, HD Jack Stand, Flush Mounted Tail Lights and Backup Lights, Ratchet Buckles, and SeaDek Fender Pads.
Duck Boat Package
Xpress Camo Paint Upgrade.
Bay Stainless Package
6 Stainless Rod Holders, Stainless Cup Holder Upgs., 4 Stainless Cleats, Stainless Steering Wheel, and Stainless Leaning Post w/o Foot Rest.
Xtreme Bay Stainless Package
Bay Stainless Package, Upgrade SS Leaning Post to Include Backrest & Footrest, and 2 Additional Stainless Cleats Midship.
Redfish Package
Two Tone Paint, Minn Kota Riptide 70 Trolling Motor Upg., Trim on the Bow, Humminbird Helix 5 Graph Upg., and Aluminum Wheel Upgrade (1 Axle).
Xtreme Redfish Package
Redfish Pkg, Minn Kota Riptide 80 Trolling Motor Upg., Humminbird Helix 9 Chirp GPS G3N Graph Upg., 2 Bank Charger, and 6 Gauge Wire Upg.
Marsh Package
Redfish Pkg, Bay Stainless Pkg , 6” Atlas Hyd. Jack Plate, Trim Gauge, Water PSI Gauge, Livewell Timer, Recirculating Baitwell, Auto Bilge, and 2 Euro Seats Upg.
Xtreme Marsh Package
Marsh Pkg, Xtreme Bay Stainless Pkg Upg., Minn Kota Riptide 80, Humminbird Helix 9 Chirp GPS G3N Graph, 2 Bank Charger, and 6 Gauge Wire Upg.
Appearance Package H-Bay (Must Upg. To Euro Fish Seat)
Custom SeaDek Liner, Matching Seat Trim, and Matching Graphics. Available in Lime, Bahama, Red, Blue and Seafoam. Click here to learn more.
